Panasonic SA-PT560E - Page 145

Ref.
No.
Part No. Part Name & Description Remarks
PCB7 REPX0631A I-POD CRADLE P.C.B [M]
(RTL)
PCB8 REPX0657B CO-PROCESSOR P.C.B [M]
(RTL)
INTERGRATED CIRCUITS
IC1701 MFI341S2095 IC IPOD VIDEO [M]
IC1702 C0CBCBC00140 IC +3.3V REGULATOR [M]
IC2001 RFKWPT460E IC SYSTEM CONTROL [M]
IC2002 C0CBCBC00140 IC REGULATOR [M]
IC2003 C3EBFY000006 IC EEPROM [M]
IC2004 C1BB00001008 IC RDS DEMODULATOR [M]
IC2101 C1AB00002735 IC AUDIO SIGNAL PROCESSOR [M]
IC2102 C0AABB000125 IC OP-AMP [M]
IC2501 C0ABBB000230 IC OP-AMP [M]
IC2801 C9ZB00000461 IC INTERGRATED [M]
IC2900 C0DAAYY00042 IC SWITCHING REGULATOR [M]
IC2903 C0DAAMH00012 IC SWITCHING REGULATOR [M]
IC3901 MN864702A IC HDMI TRANSMITTER [M]
IC3952 C0CBCDC00063 IC VOLTAGE REGULATOR [M]
IC4101 C9ZB00000461 IC VIDEO BUFFER [M]
IC4102 C1AB00001731 IC VIDEO BUFFER [M]
IC4103 C1AB00001731 IC VIDEO BUFFER [M]
IC4104 C0JBZS000003 IC QUAD ANALOG SWITHC [M]
IC5000 C1BA00000487 IC D-AMP [M]
IC5200 C1BA00000487 IC D-AMP [M]
IC5300 C1BA00000487 IC D-AMP [M]
IC5400 C1BA00000487 IC D-AMP [M]
IC5500 C0JBAB000902 IC INVERTER [M]
IC5501 C0JBAF000716 IC D-FLIP FLOP [M]
IC5701 C5HACYY00003 IC SWITCHING REGULATOR [M]
IC5799 MIP4110MSSCF IC SWITCHING REGULATOR [M]
IC5801 C0DABFC00002 IC SHUNT REGULATOR [M]
IC5899 C0DAEMZ00001 IC SHUNT REGULATOR [M]
IC6101 C0ABBB000230 IC IPOD DIFFERENTIAL AMP [M]
IC6601 C0ABAA000114 IC OP-AMP [M]
IC6602 C0CBCDG00003 IC +5V REGULATOR [M]
IC6901 C0HBB0000057 IC FL DISPLAY [M]
IC8001 MN2DS0018MP IC DV5.0 LSI [M]
IC8051 C3ABPY000011 IC 64M SDRAM [M]
IC8111 C0DBZYY00018 IC +3.3V DC-DC CONVERTER [M]
IC8151 C0DBEHG00006 IC +1.2V REGULATOR [M]
IC8251 C0GBG0000048 IC MOTOR DRIVE [M]
IC8421 C0FBBK000044 IC AUDIO DAC [M]
IC8422 C0FBAK000026 IC AUDIO DAC [M]
IC8601 C0EBA0000039 IC RESET [M]
IC8606 C0EBE0000456 IC RESET [M]
IC8611 C3EBGC000056 IC EEPROM [M]
IC8651 RFKWMH32B321 IC FLASH ROM [SPG]
IC8691 C0JBAA000502 IC AND GATE [M]
IC8695 C0JBAA000502 IC AND GATE [M]
IC8701 C0JBAB000907 IC INVERTER GATE [M]
IC8901 C0JBAA000501 IC AND GATE [M]
IC9001 C0JBAZ001251 IC LATCH [M]
IC9002 C0JBAZ001251 IC LATCH [M]
IC9003 C0JBAB000908 IC INVERTER GATE [M]
IC9005 C0DBZYY00266 IC REGULATOR [M]
TRANSISTORS
Q1702 B1CFGC000004 TRANSISTOR [M]
Q1704 B1CFGC000004 TRANSISTOR [M]
Q2001 B1ADCE000012 TRANSISTOR [M]
Q2002 B1GBCFJJ0051 TRANSISTOR [M]
Q2003 B1GBCFLL0037 TRANSISTOR [M]
Q2004 2SD0601AHL TRANSISTOR [M]
Q2005 B1ADCE000012 TRANSISTOR [M]
Q2006 B1GBCFJN0033 TRANSISTOR [M]
Q2007 B1GBCFJJ0051 TRANSISTOR [M]
Q2013 B1GBCFJJ0051 TRANSISTOR [M]
Q2030 B1GBCFJJ0051 TRANSISTOR [M]
Q2096 2SD0601AHL TRANSISTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
Q2097 2SD0601AHL TRANSISTOR [M]
Q2101 B1HBECA00004 TRANSISTOR [M]
Q2102 B1HBECA00004 TRANSISTOR [M]
Q2103 B1GDCFGA0018 TRANSISTOR [M]
Q2104 B1HBECA00004 TRANSISTOR [M]
Q2203 B1GDCFGA0018 TRANSISTOR [M]
Q2501 B1GBCFLL0037 TRANSISTOR [M]
Q2502 B1GBCFLL0037 TRANSISTOR [M]
Q2801 B1GBCFJN0033 TRANSISTOR [M]
Q2802 B1GBCFJN0033 TRANSISTOR [M]
Q2803 B1GBCFJN0033 TRANSISTOR [M]
Q2845 B1GDCFGA0018 TRANSISTOR [M]
Q2847 B1ABGC000005 TRANSISTOR [M]
Q2848 B1ABGC000005 TRANSISTOR [M]
Q2900 B1BABK000001 TRANSISTOR [M]
Q2901 B1BCCG000002 TRANSISTOR [M]
Q2902 B1ADCF000001 TRANSISTOR [M]
Q2903 B1BACG000023 TRANSISTOR [M]
Q2904 B1BACG000023 TRANSISTOR [M]
Q2909 B1ABCF000176 TRANSISTOR [M]
Q2919 B1ABCF000176 TRANSISTOR [M]
Q2921 B1ADCF000001 TRANSISTOR [M]
Q2922 B1GBCFJJ0051 TRANSISTOR [M]
Q2923 B1GBCFJJ0051 TRANSISTOR [M]
Q2924 B1GBCFJJ0051 TRANSISTOR [M]
Q3901 2SD1819A0L TRANSISTOR [M]
Q3902 B1CFHA000002 TRANSISTOR [M]
Q3903 B1CFHA000002 TRANSISTOR [M]
Q3941 2SD1819A0L TRANSISTOR [M]
Q3942 2SD1819A0L TRANSISTOR [M]
Q3943 2SD1819A0L TRANSISTOR [M]
Q4001 UNR221200L TRANSISTOR [M]
Q4002 UNR221200L TRANSISTOR [M]
Q4003 2SD0601AHL TRANSISTOR [M]
Q4004 UNR211H00L TRANSISTOR [M]
Q4005 UNR221200L TRANSISTOR [M]
Q4007 2SB0709AHL TRANSISTOR [M]
Q4008 UNR221200L TRANSISTOR [M]
Q4009 UNR221200L TRANSISTOR [M]
Q5101 B1ABCF000176 TRANSISTOR [M]
Q5102 B1ABCF000176 TRANSISTOR [M]
Q5601 B1ABCF000176 TRANSISTOR [M]
Q5602 B1ABCF000176 TRANSISTOR [M]
Q5603 B1ADCE000012 TRANSISTOR [M]
Q5604 B1ABCF000176 TRANSISTOR [M]
Q5640 B1BACD000018 TRANSISTOR [M]
Q5641 2SC584500L TRANSISTOR [M]
Q5642 2SC584500L TRANSISTOR [M]
Q5644 2SC584500L TRANSISTOR [M]
Q5720 2SC3940ARA TRANSISTOR [M]
Q5721 2SA207700L TRANSISTOR [M]
Q5722 B1ABCF000176 TRANSISTOR [M]
Q5802 B1ABCF000176 TRANSISTOR [M]
Q5803 2SC3940ARA TRANSISTOR [M]
Q5860 2SA207700L TRANSISTOR [M]
Q5861 B1ABCF000176 TRANSISTOR [M]
Q5862 B1ABCF000176 TRANSISTOR [M]
Q5898 B1ABCF000176 TRANSISTOR [M]
Q6910 B1GBCFJN0033 TRANSISTOR [M]
Q8321 2SB1218ARL TRANSISTOR [M]
Q8325 2SB1218ARL TRANSISTOR [M]
Q8331 2SB1218ARL TRANSISTOR [M]
Q8335 2SB1218ARL TRANSISTOR [M]
Q8341 2SB1218ARL TRANSISTOR [M]
Q8551 2SD1819A0L TRANSISTOR [M]
Q8552 B1ADGB000008 TRANSISTOR [M]
Q8561 2SD1819A0L TRANSISTOR [M]
Q8562 B1ADGB000008 TRANSISTOR [M]
Q8563 B1CFHA000002 TRANSISTOR [M]
Q8564 B1CFHA000002 TRANSISTOR [M]
Q8565 2SD1819A0L TRANSISTOR [M]
QR5801 UNR221400L TRANSISTOR [M]
QR5802 B1GDCFGA0018 TRANSISTOR [M]
145
SA-PT560E / SA-PT560EB / SA-PT560EG
