Panasonic SA-PT560E - Page 146

Ref.
No.
Part No. Part Name & Description Remarks
QR5810 B1GBCFLL0037 TRANSISTOR [M]
QR8111 XP0621400L TRANSISTOR [M]
QR8420 UNR521100L TRANSISTOR [M]
QR9030 B1GDCFJJ0002 TRANSISTOR [M]
DIODES
D2001 B0ACCK000005 DIODE [M]
D2005 B0ACCK000005 DIODE [M]
D2007 B0ACCK000005 DIODE [M]
D2008 B0ACCK000005 DIODE [M]
D2601 B0ACCK000005 DIODE [M]
D2602 B0ACCK000005 DIODE [M]
D2751 B0ACCK000005 DIODE [M]
D2752 B0ACCK000005 DIODE [M]
D2753 B0BC5R000009 DIODE [M]
D2754 B0BC5R000009 DIODE [M]
D2851 B0JCAE000001 DIODE [M]
D2901 B0BC035A0007 DIODE [M]
D2903 B0EAMM000057 DIODE [M]
D2904 B0JCPD000025 DIODE [M]
D2906 B0JAME000029 DIODE [M]
D2908 B0EAMM000057 DIODE [M]
D2909 MAZ82400HL DIODE [M]
D2912 B0BC3R400001 DIODE [M]
D2913 B0JCPD000025 DIODE [M]
D2915 B0ACCK000005 DIODE [M]
D2944 B0ACCK000005 DIODE [M]
D2945 B0ACCK000005 DIODE [M]
D2946 B0BC7R500001 DIODE [M]
D2947 B0BC010A0007 DIODE [M]
D2948 B0BC7R500001 DIODE [M]
D2949 B0BC5R000009 DIODE [M]
D2951 B0BC010A0007 DIODE [M]
D2961 B0BC5R000009 DIODE [M]
D2962 B0BC5R000009 DIODE [M]
D2963 B0BC5R000009 DIODE [M]
D3901 MA2J72800L DIODE [M]
D4002 B0BC01200019 DIODE [M]
D4010 B0JCAE000001 DIODE [M]
D5501 MA2J11100L DIODE [M]
D5502 MA2J11100L DIODE [M]
D5503 MAZ80510ML DIODE [M]
D5640 MAZ81200ML DIODE [M]
D5643 MA2J11100L DIODE [M]
D5644 MA2J11100L DIODE [M]
D5645 MA2J11100L DIODE [M]
D5701 B0FBAR000041 DIODE [M]
D5702 B0ZAZ0000052 DIODE [M]
D5721 MAZ81800ML DIODE [M]
D5722 B0BC019A0007 DIODE [M]
D5723 MA2J11100L DIODE [M]
D5724 MA2J11100L DIODE [M]
D5725 B0BC6R100010 DIODE [M]
D5726 B0EAKM000117 DIODE [M]
D5727 MA2J11100L DIODE [M]
D5728 MA2J11100L DIODE [M]
D5729 B0EAMM000057 DIODE [M]
D5730 MA2J11100L DIODE [M]
D5731 B0EAMM000057 DIODE [M]
D5732 B0BC035A0007 DIODE [M]
D5793 B0HAMP000094 DIODE [M]
D5797 MA2J72800L DIODE [M]
D5798 B0HAMP000094 DIODE [M]
D5801 B0HBSM000043 DIODE [M]
D5802 B0HBSM000043 DIODE [M]
D5803 B0HFRJ000012 DIODE [M]
D5804 B0EAMM000057 DIODE [M]
D5805 B0EAMM000057 DIODE [M]
D5806 MAZ80750ML DIODE [M]
D5807 MA2J11100L DIODE [M]
D5809 MA2J11100L DIODE [M]
D5896 B0EAMM000057 DIODE [M]
Ref.
No.
Part No. Part Name & Description Remarks
D6821 B3AAA0000803 LED [M]
D6910 B0BC2R4A0006 DIODE [M]
D6911 B0BC5R000009 DIODE [M]
D6913 B3ABA0000397 LED [M]
D8211 MA2J11100L DIODE [M]
DZ5701 ERZV10V511CS ZENER [M]
VARISTORS
VA3901 EZAEG2A50AX ESD SUPRESSOR [M]
VA3902 EZAEG2A50AX ESD SUPRESSOR [M]
VA3903 EZAEG2A50AX ESD SUPRESSOR [M]
VA3904 EZAEG2A50AX ESD SUPRESSOR [M]
VA3905 EZAEG2A50AX ESD SUPRESSOR [M]
VA3906 EZAEG2A50AX ESD SUPRESSOR [M]
VA3907 EZAEG2A50AX ESD SUPRESSOR [M]
VA3908 EZAEG2A50AX ESD SUPRESSOR [M]
VA3909 EZJZ0V800AA VARISTOR [M]
VA3910 EZJZ0V800AA VARISTOR [M]
VA3911 EZJZ0V800AA VARISTOR [M]
VA3912 EZJZ0V800AA VARISTOR [M]
VA3913 EZJZ0V800AA VARISTOR [M]
VA6401 EZJZ1V171AA CHIP VARISTOR [M]
VA6402 EZJZ1V171AA CHIP VARISTOR [M]
VARIABLE RESISTOR
VR6901 EVEKE2F2524B ENCODER [M]
SWITCHES
S6801 EVQ21405R SW POWER [M]
S6807 EVQ21405R SW OPEN/CLOSE [M]
S6901 EVQ21405R SW PLAY/MEMORY [M]
S6902 EVQ21405R SW BACKWARD TUNE DOWN [M]
S6903 EVQ21405R SW FORWARD TUNE UP [M]
S6904 EVQ21405R SW STOP/-TUNE MODE/-FM MODE [M]
S6905 EVQ21405R SW BOOST [M]
S6907 EVQ21405R SW SELECTOR [M]
PSW1 D4FB1R100009 SW [M]
CONNECTORS
CN1001 MFI514S0117 30P CONNECTOR [M]
CN1002 K1MN14BA0141 14P CONNECTOR [M]
CN1701 K1KB06B00038 6P CONNECTOR [M]
CN2001 K1MY50AA0029 50P CONNECTOR [M]
CN2003 K1MN14AA0003 14P CONNECTOR [M]
CN2006 K1MN07BA0004 7P CONNECTOR [M]
CN2007 K1MN17BA0005 17P CONNECTOR [M]
CN2008 K1MN28AA0004 28P CONNECTOR [M]
CN2009 K1MN17AA0004 17P CONNECTOR [M]
CN2013 K1MN04B00022 4P CONNECTOR [M]
CN2014 K1KA06AA0031 6P CONNECTOR [M]
CN2016 K1KA13AA0194 13P CONNECTOR [M]
CN2801 K1MN22AA0004 22P CONNECTOR [M]
CN4001 K1MN22BA0005 22P CONNECTOR [M]
CN5050 K1MN17AA0004 17P CONNECTOR [M]
CN5500 K1KA08AA0180 8P CONNECTOR [M]
CN5501 K1KA03AA0301 3P CONNECTOR [M]
CN5802 K1KA11AA0194 11P CONNECTOR [M]
CN6001 K1MN28AA0004 28P CONNECTOR [M]
CN6003 K1MN14AA0003 14P CONNECTOR [M]
CN6300 K1MN14AA0003 14P CONNECTOR [M]
CN6301 K1MY22A00003 22P CONNECTOR [M]
CN6401 K1KA05BA0061 5P CONNECTOR [M]
CN6402 K1FY104B0011 CONNECTOR [M]
CN6801 K1MN04AA0003 4P CONNECTOR [M]
CN6904 K1MN17AA0004 17P CONNECTOR [M]
P3901 K1FY119E0002 CONNECTOR [M]
FP8101 K1MN50AA0082 50P CONNECTOR [M]
FP8251 K1MN07AA0076 7P CONNECTOR [M]
FP8531 K1MY26AA0021 26P CONNECTOR [M]
146
SA-PT560E / SA-PT560EB / SA-PT560EG
