Panasonic SA-PT560E - Page 147

Ref.
No.
Part No. Part Name & Description Remarks
FP9001 K1KA05BA0014 5P CONNECTOR [M]
COILS AND INDUCTORS
L1001 J0JHC0000107 INDUCTOR [M]
L1002 J0JHC0000107 INDUCTOR [M]
L1003 J0JHC0000107 INDUCTOR [M]
L1004 J0JHC0000107 INDUCTOR [M]
L1005 J0JHC0000107 INDUCTOR [M]
L1006 J0JHC0000107 INDUCTOR [M]
L1007 J0JHC0000107 INDUCTOR [M]
L1008 J0JHC0000107 INDUCTOR [M]
L1009 J0JHC0000107 INDUCTOR [M]
L1010 J0JHC0000107 INDUCTOR [M]
L1011 J0JHC0000107 INDUCTOR [M]
L2101 J0JBC0000015 INDUCTOR [M]
L2201 J0JBC0000015 INDUCTOR [M]
L2701 J0JBC0000041 INDUCTOR [M]
L2703 J0JBC0000041 INDUCTOR [M]
L2801 G0A101EA0017 CHOKE COIL [M]
L2802 J0JBC0000015 INDUCTOR [M]
L2803 J0JBC0000015 INDUCTOR [M]
L2804 J0JBC0000015 INDUCTOR [M]
L2901 G0A220GA0026 CHOKE COIL [M]
L2902 G0A101ZA0028 CHOKE COIL [M]
L2903 G0A101ZA0028 CHOKE COIL [M]
L2904 G0A101EA0017 CHOKE COIL [M]
L2905 G0A100HA0023 CHOKE COIL [M]
L2907 G0A220GA0026 CHOKE COIL [M]
L2908 G0A220GA0026 CHOKE COIL [M]
L2910 G0A220GA0026 CHOKE COIL [M]
L2911 G0A200D00002 CHOKE COIL [M]
L2912 G0A220GA0026 CHOKE COIL [M]
L2913 G0A220GA0026 CHOKE COIL [M]
L2914 G0A220GA0026 CHOKE COIL [M]
L3903 G1BYYYC00026 COMMON MODE EMI FILTER [M]
L3904 G1BYYYC00026 COMMON MODE EMI FILTER [M]
L3905 G1BYYYC00026 COMMON MODE EMI FILTER [M]
L3906 G1BYYYC00026 COMMON MODE EMI FILTER [M]
L4001 J0JBC0000015 INDUCTOR [M]
L4002 J0JBC0000015 INDUCTOR [M]
L4003 J0JBC0000015 INDUCTOR [M]
L4004 J0JBC0000015 INDUCTOR [M]
L4005 J0JBC0000015 INDUCTOR [M]
L5000 G0A150L00003 CHOKE COIL [M]
L5001 G0B9R5K00003 LINE FILTER [M]
L5002 G0B9R5K00003 LINE FILTER [M]
L5200 G0A150L00003 CHOKE COIL [M]
L5201 G0B9R5K00003 LINE FILTER [M]
L5300 G0A150L00003 CHOKE COIL [M]
L5301 G0B9R5K00003 LINE FILTER [M]
L5400 G0A150L00003 CHOKE COIL [M]
L5401 G0B9R5K00003 LINE FILTER [M]
L5402 G0B9R5K00003 LINE FILTER [M]
L5500 J0JKB0000020 INDUCTOR [M]
L5501 J0JKB0000020 INDUCTOR [M]
L5701 ELF15N035AN LINE FILTER [M]
L5702 G0B932H00001 LINE FILTER [M]
L5703 ELF22V020A LINE FILTER [M]
L6901 J0JBC0000019 INDUCTOR [M]
L6903 J0JBC0000019 INDUCTOR [M]
L6910 J0JBC0000019 INDUCTOR [M]
L6920 J0JBC0000019 INDUCTOR [M]
L8001 G1C100M00049 CHIP INDUCTOR [M]
L8201 G1C100M00049 CHIP INDUCTOR [M]
L8301 G1C100M00049 CHIP INDUCTOR [M]
L8302 G1C100M00049 CHIP INDUCTOR [M]
L8303 G1C100M00049 CHIP INDUCTOR [M]
L8330 G1C100M00049 CHIP INDUCTOR [M]
L8501 G1C100M00049 CHIP INDUCTOR [M]
L8550 G1C100M00049 CHIP INDUCTOR [M]
L9004 G1BYYYC00026 COMMON MODE EMI FILTER [M]
LB3901 J0JHC0000045 INDUCTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
LB3902 J0JHC0000045 INDUCTOR [M]
LB3903 J0JCC0000042 INDUCTOR [M]
LB3904 J0JCC0000042 INDUCTOR [M]
LB3905 J0JCC0000042 INDUCTOR [M]
LB3906 J0JCC0000042 INDUCTOR [M]
LB3907 J0JHC0000045 INDUCTOR [M]
LB3908 J0JHC0000045 INDUCTOR [M]
LB6401 J0JHC0000034 INDUCTOR [M]
LB6402 J0JHC0000034 INDUCTOR [M]
LB8001 J0JHC0000045 INDUCTOR [M]
LB8011 J0JHC0000045 INDUCTOR [M]
LB8401 J0JCC0000308 INDUCTOR [M]
LB8530 J0JHC0000045 INDUCTOR [M]
LB8532 J0JDC0000045 INDUCTOR [M]
LB8551 J0JDC0000045 INDUCTOR [M]
LB8561 J0JDC0000045 INDUCTOR [M]
LB8571 J0JDC0000045 INDUCTOR [M]
LB8701 J0JCC0000308 INDUCTOR [M]
LB8702 J0JCC0000308 INDUCTOR [M]
LB8901 J0JCC0000308 INDUCTOR [M]
LB9001 J0JCC0000042 INDUCTOR [M]
TRANSFORMER
T2900 G4D1A0000117 SWITCHING TRANSFORMER [M]
T5701 ETS42BN1A6AD SWITCHING TRANSFORMER [M]
T5751 ETS19AB256AG SWITCHING TRANSFORMER [M]
COMPOMENT COMBINATION
Z6900 B3RAD0000146 REMOTE SENSOR [M]
ZA5701 K3GE1ZZ00001 FUSE HOLDER [M]
ZA5702 K3GE1ZZ00001 FUSE HOLDER [M]
PHOTO COUPLERS
PC5701 B3PBA0000402 PHOTO COUPLER [M]
PC5702 B3PBA0000402 PHOTO COUPLER [M]
PC5720 B3PBA0000402 PHOTO COUPLER [M]
PC5799 B3PBA0000402 PHOTO COUPLER [M]
OSCILLATORS
X1701 H0J327200099 CRYSTAL OSCILLATOR [M]
X2001 H2B100500007 CRYSTAL OSCILLATOR [M]
X2700 H0H433400002 CRYSTAL OSCILLATOR [M]
X5500 H2A6023A0011 CRYSTAL OSCILLATOR [M]
X5501 H2A7003A0011 CRYSTAL OSCILLATOR [M]
X8621 H0J270500085 CRYSTAL OSCILLATOR [M]
X9004 H1A4805B0027 CRYSTAL OSCILLATOR [M]
FL DISPLAY
FL6801 A2BB00000169 FL DISPLAY [M]
FUSE
F1 K5D502BNA005 FUSE [M]
FUSE PROTECTOR
FP2901 K5G401A00008 FUSE PROTECTOR [M]
THERMISTORS
TH5701 D4CAC8R00002 THERMISTOR [M]
TH5860 D4CC11040013 THERMISTOR [M]
JACKS
JK2001 K2HA5YYG0001 JK RCA PIN [M]
JK4001 K1FB121B0012 CONNECTOR [M]
JK5001 K4AL12B00002 JK SPEAKER [M]
147
SA-PT560E / SA-PT560EB / SA-PT560EG
