Digiplex/DigiplexNE LCD Keypad 23n
6.0 FEATURES FOR DGP2-641AC ONLY
The following sections pertain to the programming of options
belonging to the DGP2-641AC Access Control LCD keypad only.
6.1 ASSIGNING DOORS TO PARTITIONS
SECTION [002]: OPTIONS [1] TO [8]
Although the keypad can be programmed to display the status of
various partitions, the Access Control door can be assigned to one or
more partition(s) in the alarm system. This means that the actions
performed with the Access Control Card will be directly linked to the
partition(s) assigned to that door. For example, the keypad is
assigned to all eight partitions (see section 4.1 on page 14), but the
door is assigned to Partition 2. When the user presents the Access
Control Card to the door's reader to arm the partition, only Partition 2
will arm.
Option [1] ON = door assigned to Partition 1(default).
Option [2] ON = door assigned to Partition 2.
Option [3] ON = door assigned to Partition 3.
Option [4] ON = door assigned to Partition 4.
Option [5] ON = door assigned to Partition 5 (DigiplexNE only).
Option [6] ON = door assigned to Partition 6 (DigiplexNE only).
Option [7] ON = door assigned to Partition 7 (DigiplexNE only).
Option [8] ON = door assigned to Partition 8 (DigiplexNE only).
OFF = Access Control Cards will not be able to arm and/or
disarm partitions from the door's reader.
6.2 READER’S OPTIONS
The reader’s LED and beep features can be programmed to react in
certain ways when a specific function is performed.
