Parker AC10 series User Manual

15-2 Parameter Reference
AC10 Inverter
Function
Code
Function
Definition
Setting Range Mfr’s Value Change
F127 Skip Frequency A
0.00～590.0Hz
0.00 √
F128 Skip Width A ±2.50Hz 0.00 √
F129 Skip Frequency B
0.00～590.0Hz
0.00 √
F130 Skip Width B ±2.50Hz 0.00 √
F131 Running Display Items
0－Output frequency /
function code
1－Output rotary speed
2－Output current
4－Output voltage
8－PN voltage
16－PID feedback value
32－Temperature
64－Reserved
128－Linear speed
256－PID given value
512－Reserved
1024－Reserved
2048－Output power
4096－ Output torque
0+1＋2＋4＋
8＝15
√
F132 Display Items of Stop
0: frequency / function code
1: Keypad jogging
2: Target rotary speed
4: PN voltage
8: PID feedback value
16: Temperature
32: Reserved
64: PID given value
128: Reserved
256: Reserved
512: Setting torque
2＋4＝6
√
F133 Drive Ratio of Driven System
0.10～200.0
1.0 √
F134 Transmission-wheel Radius
0.001～1.000
0.001 √
F135 Reserved
F136 Slip Compensation
0～10
0
╳
F137 Modes of Torque Compensation
0: Linear compensation;
1: Square compensation;
2: User-defined multipoint
compensation
3: Auto torque compensation
3
╳
F138 Linear Compensation 1～20
subject to
inverter
model
╳
F139 Square Compensation
1：1.5； 2：1.8；
3：1.9； 4：2.0
1
╳
