Parker AC10 series User Manual

Parameter Reference 15-3
AC10 Inverter
Function
Code
Function
Definition
Setting Range Mfr’s Value Change
F140 User-defined Frequency Point 1
0～F142
1.00
╳
F141 User-defined voltage point 1
0～100％
4
╳
F142 User-defined frequency point 2
F140～F144
5.00
╳
F143 User-defined voltage point 2
0～100％
13
╳
F144 User-defined frequency point 3
F142～F146
10.00
╳
F145 User-defined voltage point 3
0～100％
24
╳
F146 User-defined frequency point 4 F144～F148 20.00 ╳
F147 User-defined voltage point 4
0～100％
45
╳
F148 User-defined frequency point 5
F146～F150
30.00
╳
F149 User-defined voltage point 5
0～100％
63
╳
F150 User-defined frequency point 6 F148～F118 40.00 ╳
F151 User-defined voltage point 6
0～100％
81
╳
F152
Output voltage corresponding to turnover
frequency
10～100％
100
╳
F153 Carrier frequency setting subject to inverter model
subject to
inverter
model
╳
F154 Automatic voltage rectification
Setting range:
0: Invalid 1: Valid
2:Invalid during deceleration
process
0 ╳
F155 Digital secondary frequency setting
0～F111
0
╳
F156 Digital secondary frequency polarity setting 0~1 0
╳
F157 Reading secondary frequency
△
F158 Reading secondary frequency polarity
△
F159 Random carrier-wave frequency selection
0: Control speed normally;
1: Random carrier-wave
frequency
1
F160 Reverting to manufacturer values
0: Not reverting to
manufacturer values;
1: Reverting to manufacturer
values
0
╳
