Parker AC10 series User Manual

15-4 Parameter Reference
AC10 Inverter
Running control mode: F200-F230
Function
Code
Function Definition Setting Range Mfr’s Value
Change
F200 Source of start command
0: Keypad command;
1: Terminal command;
2: Keypad＋Terminal;
3:MODBUS;
4: Keypad＋Terminal＋
MODBUS
4
╳
F201 Source of stop command
0: Keypad command;
1: Terminal command;
2: Keypad＋Terminal;
3:MODBUS;
4: Keypad＋Terminal＋MODBUS
4
╳
F202 Mode of direction setting
0: Forward running locking;
1: Reverse running locking;
2: Terminal setting
3: Keypad
0
╳
F203 Main frequency source X
0: Digital setting memory;
1: External analog AI1;
2: External analog AI2;
3: Reserved;
4: Stage speed control;
5: No memory by digital setting;
6: Reserved;;
7: Reserved;
8: Reserved;
9: PID adjusting; 10: MODBUS
0
╳
F204 Secondary frequency source Y
0: Digital setting memory;
1: External analog AI1;
2: External analog AI2;
3: Reserved;;
4: Stage speed control;
5: PID adjusting;
6: Reserved;;
0
╳
F205
Reference for selecting secondary frequency
source Y range
0: Relative to max frequency;
1: Relative to main frequency X
0
╳
F206 Secondary frequency Y range
0～100％
100
╳
F207 Frequency source selecting
0: X; 1: X+Y;
2: X or Y (terminal switchover);
3: X or X+Y (terminal switchover);
4: Combination of stage speed
and analog 5: X-Y
6: Reserved;
0 ╳
TC-Hydraulik - Rsdorfer Str. 8 - 25746 Heide - Lars Lornsen - T: +49 481 909 - 34 - l.lornsen@tc-hydraulik.de - www.tc-hydraulik.de

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
