Function Parameters 9-17
AC10 Inverter
power-down. Otherwise, inverter will run at the speed set by F113.
In case of fault under running status, inverter will reset automatically and auto-start. In case of
fault under stopped status, the inverter will only reset automatically.
When F214=0, after fault occurs, inverter will display fault code, it must be reset manually.
F215
Auto-starting delay time
Setting range:
0.1
3000.0
Mfr’s value: 60.0
F215 is the auto-starting delay time for F213 and F214. The range is from 0.1s to 3000.0s.
F216
Times of auto-
starting in case of repeated
faults
Setting range:
0
5
Mfr’s value: 0
F217 Delay time for fault reset
Setting range:
0.0
10.0
Mfr’s value: 3.0
F219
EEPROM write operation
Setting range:
0: enabled to write
;
1:
prohibit writing
Mfr
s value: 1
F216 sets the most times of auto-starting in case of repeated faults. If starting times are more
than the setting value of this function code, inverter will not reset or start automatically after fault.
Inverter will run after running command is given to inverter manually.
F217 sets delay time for fault reset. The range is from 0.0 to 10.0S which is time interval from
fault to resetting.
F220
Frequency memory after power-down
Setting range:
0: invalid;
1: valid
Mfr’s value: 0
F220 sets whether or not frequency remember after power-down is valid.
This function is valid for F213 and F214. Whether or not to memory running state after
power-down or malfunction is set by this function.
The function of frequency memory after power-down is valid for main frequency and secondary
frequency that is given by digital. Because the digital given secondary frequency has positive
polarity and negative polarity, it is saved in the function codes F155 and F156.
