Parker AC10 series User Manual

9-18 Function Parameters
AC10 Inverter
Table 9-1 Combination of Speed Control
F204
F203
0. Memory of
digital setting
1 External
analog AI1
2 External
analog AI2
4 Terminal stage
speed control
5 PID
adjusting
0
Memory of
d
igital setting
〇
● ● ● ●
1External analog AI1
●
〇
● ● ●
2External analog AI2
● ●
〇
● ●
4Terminal Stage
speed
control
● ● ●
〇
●
5 Digital setting
〇
● ● ● ●
9 PID adjusting
● ● ● ●
〇
10 MODBUS
● ● ● ● ●
●: Inter-combination is allowable.
〇: Combination is not allowable.
The mode of automatic cycle speed control is unable to combine with other modes. If the
combination includes the mode of automatic cycle speed control, only main speed control mode
will be valid.
224=1, when target frequency is lower than Min frequency, inverter will run at Min frequency.
·
F228 can be set to Mfr’s value by F160=1.
F224 when target frequency is lower than
Min frequency
Setting range:
0: stop
1: run at min frequency
Mfr’s value: 1
F228 Application selection
Setting range:
0: Invalid
1: Basic speed control
2: Auto/manual speed control
3: Preset speed control
4: Terminal speed control
5: PID control
Mfr’s value: 0
TC-Hydraulik - Rsdorfer Str. 8 - 25746 Heide - Lars Lornsen - T: +49 481 909 - 34 - l.lornsen@tc-hydraulik.de - www.tc-hydraulik.de

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
