Parker AC10 series User Manual

Function Parameters 9-21
AC10 Inverter
F310
Characteristic current
Setting range: 0
～1000
Mfr’s value: Rated
current
F311
Characteristic current width
Setting range
: 0～100
Mfr’s value: 10
When F300=17 or F301=17 or token characteristic current is selected, this group function
codes set characteristic current and its width.
For example: setting F301=17, F310=100, F311=10, when inverter current is higher than F310,
DO1 outputs ON signal. When inverter current is lower than （100-100*10%）=90A, DO1 outputs
OFF signal.
F312
Frequency arrival threshold
At Speed
Setting range: 0.00
～5.00Hz
Mfr’s value: 0.00
When F300=15 or F301=15, threshold range is set by F312.
For example: when F301=15, target frequency is 20HZ and F312=2, the running frequency
reaches 18Hz (20-2), ON signal is output by DO1 until the running frequency reaches target
frequency.
TC-Hydraulik - Rsdorfer Str. 8 - 25746 Heide - Lars Lornsen - T: +49 481 909 - 34 - l.lornsen@tc-hydraulik.de - www.tc-hydraulik.de

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
