Parker COMPAX-M /-S (L) User Manual

Start-up manual
COMPAX-M / -S
Resolver / SinCos
50
SinCos



cable for HJ and HDY motors
2
7
10
7
+8V
GND
+V
GND
9
10
9
8
Th1
Th2
K1
K2
15
8
13
3
ST-
ST+
+485
-485
12
11
12
11
COS-
COS+
COS-
COS+
5
13
0r
red
blue
green
grey
pink
black
white
brown
violet
yellow
2
1
0r
rt
bl
gn
gr
rs
sw
ws
br
vio
ge
SIN-
SIN+
SIN-
SIN+
screen at
sceen contact
LiYC11Y 4x2x0,25+2x0,5+0,14
No. 102-150210
2x0,5
1x0,14
2x0,25
2x0,25
2x0,25
2x0,25
solder side
1
2
3
4
5
10
11
12
13
6
7
8
14
15
9
Pin 1
Packing according as the regulation of the manufacturer
solder- / Crimp side
8
4
6
57
3
2
1
9
16
11
10
12
13
15 14
17
8 x Crimp contacts 0.14-0.56
GBK16
4 mm
6 mm
26 mm
27
Version in high-flex: GBK17 (same layout)
Packaging
Packaging of motor in accordance with connector manufacturer's specification
Packaging of device
•
Strip 26mm sheathing off.
•
Cut sheath down to 6 mm.
•
Strip 4mm of insulation of ends and coat in tin.
•
Place sheath over large area of housing (e.g. fold sheath over outer cover and fasten down by relieving tension).
