Parkside PTBMOD 710 C3 - General Description; Extent of the Delivery; Description of Functions; Overview

23
GB MT
Intended purpose
The bench drill is designed for drilling in
metal, wood and plastic. It can be used
with drill bits of 1 mm to 13 mm diameter.
The device is intended to be used by do-it-
yourselfers. It was not designed for heavy
commercial use. Commercial use will inva-
lidate the guarantee.
The tool is not to be used by persons.
under the age of 16. Children over the
age of 16 may use the tool except under
supervision.
The manufacturer is not liable for damage
caused by an improper use or incorrect
operation of this device.
General description
An illustration of the most im-
portant functional components
can be found on the front and
the back fold-out pages.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete. Dispose of the pa
ckaging material correctly.
· Motor unit
· Quick clamp
· Baseplate
· Lifting wheel + cover +Phillips screw
· Clamping lever
· Crank handle + Phillips screw
· Safety shield +2xPhillips screws
· Drill chuck
· Parallel guide
· Drill chuck key
· 2x hex key
(small: 3mm + large: 4mm)
· Cover
- Instruction Manual
Description of functions
Please refer to the descriptions below for
information about the operating devices.
Overview
1 Motor unit
2 Off switch
3 On switch
4 Controller
5 Safety shield
6 Lever
7 Parallel guide
8 Quick clamp
9 Column tube
10 Clamping lever
11 Crank handle
12 Locking screw (depth stop)
13 On/Off switch
14 Lifting wheel
15 Baseplate
16 Wing screw
17 Drill chuck
18 Cover
19 Large Phillips screw
20 Small Phillips screws
21 Drill chuck key
22 Small Phillips screw
23 Large hex key
24 Small hex key
25 Short grub screw
26 Long grub screw
27 Thread
28 Cover
29 Grub screw
