12
table 1.3.
Table 1.3
Marking of
the probe
type
103 НВ (103 НV)
209 НВ (212
НV)
406 НВ (420
НV) (42,5 НRС)
763 НV (63,0
НRС)
D
0,80
0,72
0,67
0,57
G
1,29
1,22
0,93
-
Е
0,80
0,72
0,67
0,57
UCI
0,23
0,16
0,13
0,09
The average conditional depths of impressions (mm) created on the surface of the
product when measuring different hardness (for carbon structural steels) are shown in table
1.4.
Table 1.4
Marking of
the probe
type
103 HB (103 НV)
209 НВ (212
НV)
406 НВ (420
НV) (42,5 НRС)
763 НV (63,0
НRС)
D
0,054
0,043
0,038
0,027
G
0,084
0,075
0,044
-
Е
0,054
0,043
0,038
0,027
UCI
0,066
0,045
0,05
0,037
Table 1.5 - Parameters of holes/grooves for the Ultrasonic probe
Hole/groove diameter from, μm
Hole/groove depth up to, μm
with spout (normal)
without spout
with spout (normal)
without spout
10
5
18
23
1.6 Additional devices and accessories
The hardness tester, at the request of the user, can be in addition completed with the
cordless grinder - for the preparation of a surface in a measuring zone (reduction of roughness,
removal of a scale, rust, a ruffle, and processing of welds).
