2.4 Measurement tab

In the measurements tab you can choose:

• calibration on a given scale,

• scales for measurement conversion,

• probe directions,

• a number of measurements in series.

2.4.1 Selection of calibration scale

To select the calibration according to a given scale, press the button , then the

calibration selection window will open (Fig. 2.6)

Figure 2.6 - Calibration selection window

You can use the buttons to select standard or custom calibration. Use the

buttons to select the desired calibration value and press the button , then return

to the "Measurements" tab. If calibration has not been selected, press the button to return to

the "Measurement" tab .
