PCE Instruments PCE-3000ULS - Custom Calibration

43
2.7 Custom calibration
Custom calibration is intended for the user to create their calibrations on their materials.
The user can add new calibrations for different materials and adjust the values of
custom calibrations already created by him. To do this, use the buttons to select
"Custom" (Fig. 2.32), then press the button . A window for entering the password will
appear (Fig. 2.33), enter the password using the buttons
. After entering the password, a window will open with three options:
"Create scale", "Edit name" and "Delete scale" (Fig. 2.34).
Figure 2.32 -
Calibration" tab
Figure 2.33 -
Password entry window
Figure 2.34 - Items in
the custom calibration
2.7.1 "Create scale" item
Use the buttons to select "Create scale" and click on the window that
opens, the user will be prompted to enter the calibration name (Fig. 2.35).
