42
2.6.3 Delete scale item
To delete the calibration scale, use the buttons , to select "Delete scale" and
press the button (Fig. 2.16). In the tab that opens, select the scale you want to delete and
click (Fig. 2.30). After that the window of confirmation of removal of calibration will
open (fig. 2.31), buttons select "Yes" or "No" and press .
Figure 2.30 - View tab "Delete scale"
Figure 2.31 - Delete calibration
