9
1.4 Technical specifications
Table 1.1
10 HB –
in range 90-180 HB
15 HB –
in range 180-250 HB
20 HB –
in range 250-460 HB
15 HV – in range
240-500 HV
20 HV – in range
500-800 HV
25 HV – in range
800-940 HV
Probe UCI – Diamond indenter
Leeb Probe - Hardened Ball
Diameter of the platform
for installing the probe
For ultrasonic probe:
- From 1 mm on the plane,
– from 5 mm/0.197" in
a blind hole (groove)
For dynamic probe:
from 10 mm/0.394" on the
plane
Ultrasonic Sensor (UCI) - pre-calibrated for steel
Dynamic (Leeb) with pre-calibration for steel, cast iron,
stainless steel, aluminium, bronze, brass, copper
Additional Custom Calibration Materials
Algorithm for discarding
incorrect measurements
Average value from 1 to 20 measurements
Minimum, maximum, average value
search for results of incorrect measurements
Converting the measured hardness into different scales
Drop-proof plastic housing with rubber bumper
- 20 ... +45 °С / -4 …113 °F / non-condensing
All points in the series included in the calculation of the
average
English, Ukrainian, Russian
USB cable, the ability to customize and process the results
Product surface
roughness
for probe type "UCI":
1,6 Ra
for probe type "D": 3.2 Ra
for probe type "G": 7.2 Ra
for probe type "E": 1.6 Ra
183×93×42 mm / 7.2 x 3.7 x 1.7 "
300 g / < 1 lb. (without probe)
