Relion 1900e/2900e Manual
Revision 1.0 112
13. Power Supply Specification Guidelines
This section provides power supply specification guidelines recommended for providing the specified server
platform with stable operating power requirements.
Note:
The power supply data provided in this section is for reference purposes only. It reflects Intel’s own DC
power out requirements for a 750W power supply as used in an Intel designed 2U server platform. The
intent of this section is to provide customers with a guide to assist in defining and/or selecting a power
supply for custom server platform designs that utilize the server board detailed in this document.
13.1 Power Supply DC Output Connector
The server board includes two main power slot connectors allowing for power supplies to attach directly to
the server board. Power supplies must utilize a card edge output connection for power and signal that is
compatible with a 2x25 Power Card Edge connector (equivalent to 2x25 pin configuration of the FCI power
card connector 10035388-102LF).
Table 50. Power Supply DC Power Output Connector Pinout
Pin
Name
Pin
Name
A1
GND
B1
GND
A2
GND
B2
GND
A3
GND
B3
GND
A4
GND
B4
GND
A5
GND
B5
GND
A6
GND
B6
GND
A7
GND
B7
GND
A8
GND
B8
GND
A9
GND
B9
GND
A10
+12V
B10
+12V
A11
+12V
B11
+12V
A12
+12V
B12
+12V
A13
+12V
B13
+12V
A14
+12V
B14
+12V
A15
+12V
B15
+12V
A16
+12V
B16
+12V
A17
+12V
B17
+12V
A18
+12V
B18
+12V
A19
PMBus SDA
B19
A0 (SMBus address)
A20
PMBus SCL
B20
A1 (SMBus address)
A21
PSON
B21
12V stby
A22
SMBAlert#
B22
Cold Redundancy Bus
A23
Return Sense
B23
12V load share bus
A24
+12V remote Sense
B24
No Connect
A25
PWOK
B25
Compatibility Check pin*
