Relion 1900e/2900e Manual
Revision 1.0 44
Figure 20. SATA RAID 5 Upgrade Key
 Maximum drive support = 6 (Maximum on-board SATA port support)
 Open Source Compliance = Binary Driver (includes Partial Source files) or Open Source using MDRAID
layer in Linux*.
Note: RAID configurations cannot span across the two embedded AHCI SATA controllers.
5.7 Network Interface
On the back edge of the server board are three RJ45 networking ports; “NIC #1”, “NIC #2”, and a Dedicated
Management Port.
Figure 21. Network Interface Connectors
Each ethernet port drives two LEDs located on each network interface connector. The LED at the left of the
connector is the link/activity LED and indicates network connection when on, and transmit/receive activity
when blinking.
The L
ED at the right of the connector indicates link speed as defined in the following table.
