Relion 1900e/2900e Manual
45 Revision 1.3
Figure 22. External RJ45 NIC Port LED Definition
NOTE: Lowest, Mid-range, and Highest supported data rate is dependent on which onboard networking
controller option is present. See section 5.7.1 for details on available onboard network controller options.
5.7.1 Intel® Ethernet Controller Options
The server board is offered with the following Intel
®
Ethernet Controller options:
• Intel
®
Ethernet Controller X540 10 GbE (Server board product code - S2600WTTR)
• Intel
®
Ethernet Controller I350 1 GbE (Server board product code - S2600WT2R)
Refer to the respective product data sheets for a complete list of supported Ethernet Controller features.
5.7.2 Factory Programmed MAC Address Assignments
Depending on which onboard ethernet controller is present, the server board may have 5 or 7 MAC
addresses programmed at the factory. MAC addresses are assigned as follows:
• NIC #
1 MAC address = Base #
• NIC # 2 MAC address = Base # + 1
• BMC LAN channel 0 MAC address = Base # + 2
• BMC LAN channel 1 MAC address = Base # + 3
• Dedicated On-board Management Port MAC address = Base # + 4
The fo
llowing MAC address assignments are used for FCoE support on server boards with an on-board Intel
®
Ethernet Controller X540:
• NIC
#1 SAN MAC address = Base # + 5
• NIC #2 SAN MAC address = Base # + 6
The
base MAC address will be printed on a label and affixed to the server board and/or Intel server system.
Factory programmed MAC addresses can also be viewed in the <F2> BIOS Setup Utility.
5.8 Video Support
The graphics controller of the integrated baseboard management controller provides support for the
following features as implemented on the server board:
 Integrated Graphics Core with 2D Hardware accelerator
 DDR-3 memory interface with 16 MB of memory allocated and reported for graphics memory
 High speed Integrated 24-bit RAMDAC
 Single lane PCI-Express host interface running at Gen 1 speed
LED
Color
LED State
NIC State
Left Green
Off
LAN link not established
On
LAN link is established
Blinking
Transmit / Receive Activity
Right
Off
Lowest supported data rate
Amber
On
Mid-range supported data rate
Green
On
Highest supported data rate
