Relion 1900e/2900e Manual
Revision 1.3 132
Appendix C – Management Engine Generated SEL Event
Messages
This appendix lists the OEM System Event Log message format of events generated by the Management
Engine (ME). This includes the definition of event data bytes 10-16 of the Management Engine generated SEL
records. For System Event Log format information, see the Intelligent Platform Management Interface
Specification, Version 2.0.
Table 58. Server Platform Services Firmware Health Event
Server Platform Services Firmware
Health Event
Request
Byte 1
- EvMRev
=04h (IPMI2.0 format)
Byte 2
– Sensor Type
=DCh (OEM)
Byte 3
– Sensor Number
=
23 – Server Platform Services Firmware Health
Byte 4
– Event Dir | Event Type
[7]
– Event Dir
=0 Assertion Event
[6
-0] – Event Type
=7
5h (OEM)
Byte 5
– Event Data 1
[7,6]=10b
– OEM code in byte 2
[5,4]=
10b – OEM code in byte 3
[3..0]
– Health Event Type
=0
0h –Firmware Status
Byte 6
– Event Data 2
=0
- Forced GPIO recovery. Recovery Image loaded due to MGPIO<n> (default recovery pin is
MGPIO1)
pin asserted.
Repair action:
Deassert MGPIO1 and reset the ME
=1
- Image execution failed. Recovery Image loaded because operational image is corrupted.
This
may be either caused by Flash device corruption or failed upgrade procedure.
Repair action:
Either the Flash device must be replaced (if error is persistent) or the upgrade
procedure must be sta
rted again.
=
2 - Flash erase error. Error during Flash erases procedure probably due to Flash part
corruption.
Repair action:
The Flash device must be replaced.
=
3 – Flash corrupted. Error while checking Flash consistency probably due to Flash part
corruption.
Repair action:
The Flash device must be replaced (if error is persistent).
=
4 – Internal error. Error during firmware execution.
Repair action:
FW Watchdog Timeout
Operational image shall be upgraded to other version or hardware board repair is needed (if
error is
persistent).
=
5..255 – Reserved
Byte
7 – Event Data 3
=<
Extended error code. Should be used when reporting an error to the support>
