Revision 1.3 152
Relion 1900e/2900e Manual
Relion 2900e
Figure 37. Relion 2900e
Table 68. Relion 2900e Product Family Feature Set
Server Board Options
Relion 2900e w/Dual 1GbE ports – S2600WT2R
•
Relion 2900e w/Dual 10GbE ports – S2600WTTR
Processor Support
• Two LGA2011-3 (Socket R3) processor sockets
• Support for one or two Intel
®
Xeon
®
processors E5-2600 v3, v4 product family
• Maximum supported Thermal Design Power (TDP) of up to 145 W.
Memory
• 24 DIMM slots – 3 DIMMs/Channel – 4 memory channels per processor
• Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM)
• Memory data transfer rates:
o DDR4 RDIMM: 1600 MT/s (3DPC), 1866 MT/s (2DPC) and 2133 MT/s (1DPC)
o DDR4 LRDIMM: 1600 MT/s (3DPC), 2133 MT/s (2DPC & 1DPC)
• DDR4 standard I/O voltage of 1.2V
