Relion 1900e/2900e Manual
153 Revision 1.3
Feature
Description
External I/O connections
• DB-15 Video connectors
o Front and Back on non-storage systems
o Back only on storage systems (12 x 3.5” and 24 x 2.5” drive support)
• RJ-45 Serial Port A connector
• Dual RJ-45 Network Interface connectors supporting either :
o 10 GbE RJ-45 connectors (Intel Server Board Product Code – S2600WTTR)
or
o 1 GbE RJ-45 connectors (Intel Server Board Product Code – S2600WT2R)
• Dedicated RJ-45 server management port
• Three USB 2.0 / 3.0 connectors on back panel
• Two USB 2.0 / 3.0 ports on front panel (non-storage models only)
• One USB 2.0 port on rack handle (storage models only)
Internal I/O connectors /
headers
• One Type-A USB 2.0 connector
• One 2x5 pin connector providing front panel support for two USB 2.0 ports
• One 2x10 pin connector providing front panel support for two USB 2.0 / 3.0 ports
• One 2x15 pin SSI-EEB compliant front panel header
• One 2x7pin Front Panel Video connector
• One 1x7pin header for optional Intel
®
Local Control Panel (LCP) support
• One DH-10 Serial Port B connector
I/O Module Accessory
Options
The server board includes a proprietary on-board connector allowing for the installation of a variety of
available I/O modules. An installed I/O module can be supported in addition to standard on-board
features and add-in PCIe* cards.
• AXX4P1GBPWLIOM – Quad port RJ45 1 GbE based on Intel® Ethernet Controller I350
• TBD – Dual port RJ-45 10GBase-T I/O Module based on Intel® Ethernet Controller x540
• AXX10GBNIAIOM – Dual port SFP+ 10 GbE module based on Intel® 82599 10 GbE controller
• AXX1FDRIBIOM – Single port QSFP FDR 56 GT/S speed InfiniBand* module
• AXX2FDRIBIOM – Dual port QSFP FDR 56 GT/S speed infiniband* module
• AXX1P40FRTIOM – Single port QSFP+ 40 GbE module
• AXX2P40FRTIOM – Dual port QSFP+ 40 GbE module
System Fans
• Six managed hot swap system fans
• One power supply fan for each installed power supply module
Riser Card Support
Support for three riser cards.
• Riser #1 – PCIe* Gen3 x24 – up to 3 PCIe* slots
• Riser #2 – PCIe* Gen3 x24 – up to 3 PCIe* slots
• Riser #3 – PCIe* Gen3 x8 + DMI x4 (operating in PCIe* mode) – up to 2 PCIe* slots (Optional)
With three riser cards installed, up to 8 possible add-in cards can be supported:
• 4 Full Height / Full Length + 2 Full Height / Half Length add-in cards via Risers #1 and #2
• 2 low profile add-in cards via Riser #3 (option)
• See Chapter 10 for available riser card options.
Video
• Integrated 2D Video Controller
• 16 MB DDR3 Memory
