2. Product Features Overview
The S2600WT is a monolithic printed circuit board assembly with features that are intended for high
density 1U and 2U rack mount servers. This server board is designed to support the Intel
®
Xeon
®
processor E5-2600 v3, v4 product family. Previous generation Intel
®
Xeon
®
processors are not supported.
The s
erver board is offered with either of the two following on-board networking options:
• Intel
®
Ethernet Controller X540, supporting 10 GbE (Intel Server Board Product Code - S2600WTTR)
• Intel
®
Ethernet Controller I350, supporting 1 GbE (Intel Server Board Product Code – S2600WT2R)
All ot
her onboard features will be identical.
Table 1. Relion 1900e/2900e Feature Set
Feature
Description
Processor Support
• Two LGA2011-3 (Socket R3) processor sockets
• Support for one or two Intel
®
Xeon
®
processors E5-2600 v3, v4 product family
• Maximum supported Thermal Design Power (TDP) of up to 145 W
Memory
• 24 DIMM slots – 3 DIMMs/Channel – 4 memory channels per processor
• Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM)
• Memory data transfer rates:
o DDR4 RDIMM: 1600 MT/s (3DPC), 1866 MT/s (2DPC) and 2133 MT/s (1DPC)
o DDR4 LRDIMM: 1600 MT/s (3DPC), 2133 MT/s (2DPC & 1DPC)
• DDR4 standard I/O voltage of 1.2V
Chipset
Intel
®
C612 chipset
External (Back Panel)
I/O connections
• DB-15 Video connector
• RJ-45 Serial Port A connector
• Dual RJ-45 Network Interface connectors supporting either :
o 10 GbE RJ-45 connectors (Intel Server Board Product Code – S2600WTTR)
or
o 1 GbE RJ-45 connectors (Intel Server Board Product Code – S2600WT2R)
• Dedicated RJ-45 server management port
• Three USB 2.0 / 3.0 ports
Internal I/O
connectors/headers
• One Type-A USB 2.0 connector
• One 2x5 pin connector providing front panel support for two USB 2.0 ports
• One 2x10 pin connector providing front panel support for two USB 2.0 / 3.0 ports
• One 2x15 pin SSI-EEB compliant Standard Front Panel header
• One 2x15 high density Storage Front Panel connector
• One 2x7pin Front Panel Video connector
• One 1x7pin header for optional Intel
®
Local Control Panel support
• One DH-10 Serial Port B connector
PCIe* Support
• PCIe* 3.0 (2.5, 5, 8 GT/s) – backwards compatible with PCIe* Gen 1 and Gen 2 devices
1U Server – Riser Card
Support
• Server board includes two PCIe* 3.0 compatible riser card only slots
o Riser #1 – PCIe* 3.0 x24 – 1 PCIe* Full Height / Half Length add-in card support in 1U
o
Riser #2 – PCIe* 3.0 x24 – 1 PCIe* Full Height / Half Length add-in card support in 1U
