Penguin Computing Relion 1900e - Page 18

Relion 1900e/2900e Manual
3 Revision 1.3
Feature
Description
2U Server – Riser Card
Support
• Server board includes three PCIe* 3.0 compatible riser card only slots:
o Riser #1 – PCIe* 3.0 x24 – up to 3 PCIe* slots in 2U
o Riser #2 – PCIe* 3.0 x24 – up to 3 PCIe* slots in 2U
o Riser #3 – PCIe* 3.0 x8 + DMI x4 (PCIe* 2.0 compatible) – up to 2 PCIe* slots in 2U
• With three riser cards installed, up to 8 possible add-in cards can be supported:
o 4 Full Height / Full Length + 2 Full Height / Half Length add-in cards via Risers #1 and #2
o 2 low profile add-in cards via Riser #3
Available I/O Module
Options
The server board includes a proprietary on-board connector allowing for the installation of a variety of
available I/O modules. An installed I/O module can be supported in addition to standard on-board
features and add-in PCIe* cards.
• AXX4P1GBPWLIOM – Quad port RJ45 1 GbE based on Intel® Ethernet Controller I350
• AXX10GBTWLIOM3 – Dual port RJ-45 10GBase-T I/O Module based on Intel® Ethernet Controller
x540
• AXX10GBNIAIOM – Dual port SFP+ 10 GbE module based on Intel® 82599 10 GbE controller
• AXX1FDRIBIOM – Single port QSFP FDR 56 GT/S speed InfiniBand* module
• AXX2FDRIBIOM – Dual port QSFP FDR 56 GT/S speed infiniband* module
• AXX1P40FRTIOM – Single port QSFP+ 40 GbE module
• AXX2P40FRTIOM – Dual port QSFP+ 40 GbE module
System Fan Support
• Six system fans supported in two different connector formats: hot swap (2U) and cabled (1U)
o Six 10-pin managed system fan headers (Sys_Fan 1-6) – Used for 1U system configuration
o Six 6-pin hot swap capable managed system fan connectors (Sys_Fan 1-6) – Used for 2U system
configuration
Video
• Integrated 2D Video Controller
• 16 MB DDR3 Memory
On-board storage
controllers and
options
• 10x SATA 6Gbps ports (6Gb/s, 3 Gb/s and 1.5Gb/s transfer rates are supported)
o Two 7-pin single port SATA connectors capable of supporting up to 6 Gb/sec
o Two 4-port mini-SAS HD (SFF-8643) connectors capable of supporting up to 6 Gb/sec SATA
• One eUSB 2x5 pin connector to support 2mm low-profile eUSB solid state devices
• Optional SAS IOC/ROC support via on-board Intel® Integrated RAID module connector
• Embedded Software SATA RAID
o Intel
®
Rapid Storage RAID Technology (RSTe) 4.1
o
Intel
®
Embedded Server RAID Technology 2 (ESRT2) 1.41 with optional RAID 5 key support
Security
• Intel
®
Trusted Platform Module (TPM) - AXXTPME5 (1.2), AXXTPME6 (v2.0) and AXXTPME7 (v2.0)
(Accessory Option)
Server Management
• Integrated Baseboard Management Controller, IPMI 2.0 compliant
• Support for Intel
®
Server Management Software
• On-board RJ45 management interface
• Intel
®
Remote Management Module 4 Lite support (Accessory Option)
