Relion 1900e/2900e Manual
Revision 1.0 130
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicabil
ity
Sensor Type
Event/Rea
ding Type
Event Offset Triggers
Contrib. To
System Status
Assert
/De-
assert
Readabl
e
Value/
Offsets
Event
Data
Rearm
Stand-
by
Processor 1 DIMM
Thermal Trip
(P1 Mem Thrm Trip)
C0h All
Memory
0Ch
Sensor
Specific
6Fh
0A- Critical
overtemperature
Fatal
As
and
De
– Trig Offset M -
Processor 2 DIMM
Thermal Trip
(P2 Mem Thrm Trip)
C1h All
Memory
0Ch
Sensor
Specific
6Fh
0A- Critical
overtemperature
Fatal
As
and
De
– Trig Offset M -
Processor 3 DIMM
Thermal Trip
(P3 Mem Thrm Trip)
C2h
Platform
Specific
Memory
0Ch
Sensor
Specific
6Fh
0A- Critical
overtemperature
Fatal
As
and
De
– Trig Offset M X
Processor 4 DIMM
Thermal Trip
(P4 Mem Thrm Trip)
C3h
Platform
Specific
Memory
0Ch
Sensor
Specific
6Fh
0A- Critical
overtemperature
Fatal
As
and
De
– Trig Offset M X
MIC 1 Temp
(GPGPU1 Core Temp)
C4h
Platform
Specific
Temperature
01h
Threshold
01h
- - - - - - -
MIC 2 Temp
(GPGPU2 Core Temp)
C5h
Platform
Specific
Temperature
01h
Threshold
01h
- - - - - - -
MIC 3 Temp
(GPGPU3 Core Temp)
C6h
Platform
Specific
Temperature
01h
Threshold
01h
- - - - - - -
MIC 4 Temp
(GPGPU4 Core Temp)
C7h
Platform
Specific
Temperature
01h
Threshold
01h
- - - - - - -
Global Aggregate
Temperature Margin 1
(Agg Therm Mrgn 1)
C8h
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Global Aggregate
Temperature Margin 2
(Agg Therm Mrgn 2)
C9h
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Global Aggregate
Temperature Margin 3
(Agg Therm Mrgn 3)
CAh
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Global Aggregate
Temperature Margin 4
(Agg Therm Mrgn 4)
CBh
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
