Relion 1900e/2900e Manual
Revision 1.3 150
Feature
Description
External I/O
connections
• DB-15 Video connectors
o Front and Back on non-storage systems
o Back only on storage systems (12 x 3.5” and 24 x 2.5” drive support)
• RJ-45 Serial Port A connector
• Dual RJ-45 Network Interface connectors supporting either :
o 10 GbE RJ-45 connectors (Intel Server Board Product Code – S2600WTTR)
or
o 1 GbE RJ-45 connectors (Intel Server Board Product Code – S2600WT2R)
• Dedicated RJ-45 server management port
• Three USB 2.0 / 3.0 connectors on back panel
• Two USB 2.0 / 3.0 ports on front panel (non-storage models only)
Internal I/O connectors
/ headers
• One Type-A USB 2.0 connector
• One 2x5 pin connector providing front panel support for two USB 2.0 ports
• One 2x10 pin connector providing front panel support for two USB 2.0 / 3.0 ports
• One 2x15 pin SSI-EEB compliant front panel header
• One 2x7 pin Front Panel Video connector
• One 1x7 pin header for optional Intel
®
Local Control Panel (LCP) support
• One DH-10 Serial Port B connector
I/O Module Accessory
Options
The server board includes a proprietary on-board connector allowing for the installation of a variety of
available I/O modules. An installed I/O module can be supported in addition to standard on-board
features and add-in PCIe* cards.
• AXX4P1GBPWLIOM – Quad port RJ45 1 GbE based on Intel
®
Ethernet Controller I350
• TBD – Dual port RJ-45 10GBase-T I/O Module based on Intel
®
Ethernet Controller x540
• AXX10GBNIAIOM – Dual port SFP+ 10 GbE module based on Intel
®
82599 10 GbE controller
• AXX1FDRIBIOM – Single port QSFP FDR 56 GT/S speed InfiniBand* module
• AXX2FDRIBIOM – Dual port QSFP FDR 56 GT/S speed infiniband* module
• AXX1P40FRTIOM – Single port QSFP+ 40 GbE module
• AXX2P40FRTIOM – Dual port QSFP+ 40 GbE module
System Fans
• Six dual rotor managed system fans
• One power supply fan for each installed power supply module
Riser Card Support
Concurrent support for two PCIe* riser cards. Each riser card slot has support for the following riser
card options:
• Single add-in card slot – PCIe* x16, x16 mechanical
Video
• Integrated 2D Video Controller
• 16 MB DDR3 Memory
On-board storage
controllers and options
• 10 x SATA 6Gbps ports (6Gb/s, 3 Gb/s and 1.5Gb/s transfer rates are supported)
• Two single port SATA connectors capable of supporting up to 6 Gb/sec
• Two 4-port mini-SAS HD (SFF-8643) connectors capable of supporting up to 6 Gb/sec SATA
• One eUSB 2x5 pin connector to support 2mm low-profile eUSB solid state devices
• Optional SAS IOC/ROC support via on-board Intel® Integrated RAID module connector
• Embedded Software SATA RAID
o Intel
®
Rapid Storage RAID Technology (RSTe) 4.0
o
Intel
®
Embedded Server RAID Technology 2 (ESRT2) with optional RAID 5 key support
Security
• Intel
®
Trusted Platform Module (TPM) - AXXTPME5 (v1.2), AXXTPME6 (v2.0) and AXXTPME7 (v2.0)
(Accessory Option)
