4. Specification
4.1 General Dimensions
All values are approxmate
Overall heght 380 mm
Wdth 186 mm
Depth 240 mm
Weght (empty) 57 kg
Mountng system Polemount assembly
4.2 Resistance of Breathing System
4.2.1 Resistance Measurement Parameters
Resstances lsted n secton 422 and secton 423 are
measured wth
a) An absorber ftted wth 1060 mm (42 nch) breathng
hoses complyng wth BS EN ISO 5367, and a Safelock
Y-pece
b) Absorber only
NOTE
1 The canster must be flled to the correct level wth fresh
absorbent (follow the nstructons n secton 53)
2 A bacteral flter must be used n the patent breathng
system to protect the oxygen sensor
Use an approprate flter that does not rase the resstance
values of the whole system to above 06 kPa (6 cmHO)
3 The adustable pressure lmtng (APL) valve must be fully
open
4.2.2 Expiratory Resistance
Tested, as detaled n secton 421, wth a flow of 6 L/mn of
ar through the fresh gas nlet and an nduced flow of 60 L/mn
through the breathng system
a) Expratory resstance Less than 06 kPa (6 cmHO)
b) Expratory resstance Less than 05 kPa (5 cmHO)
4.2.3 Inspiratory Resistance
Tested, as detaled n secton 421, wth a flow of 6 L/mn of
ar through the fresh gas nlet and an nduced flow of 60 L/mn
through the breathng system
a) Inspratory resstance Less than 06 kPa (6 cmHO)
b) Inspratory resstance Less than 045 kPa (45 cmHO)
