Penlon A200SP - Reassembly Procedures; Ventilator Bellows and Absorber Reassembly

A200SP Absorber 34 User Manual
Sterilisation
8.6 Absorber Assembly Reassembly after
Cleaning and Sterilisation
AUTION
When the absorber s lfted or carred by hand, always
support the weght of the unt under the base
Do not lft the absorber by grppng any of the components
attached to the manfold block - see secton 51
8.6.1 Ventilator Bellows
AUTION
After cleanng, check that the small O-rng (1) located n
the bellows base under the daphragm valve s n place The
ventlator wll not functon f the O-rng s mssng
1 Reft the exhalaton daphragm valve assembly (2) to the
bellows base
2 Reft the bellows assembly (3) and housng (4)
AUTION
heck for correct ftment of the bellows (3) Functon test
the ventlator before clncal use (refer to ventlator user
manual)
8.6.2 Absorber
Reverse the dsmantlng procedure gven n secton 84
Refllng
1 Reft the contaner or pre-pack
Pre-packed soda lme
heck that the three spacers (1) are n place
heck that the carrer (2) s n place
Insert the pre-pack nto the carrer n the canster
Bulk packed (loose) soda lme
heck that the three spacers (1) are n place, and place the
contaner n the canster
2 Reft the absorbent canster
Warnng
The canster seals at the top face Mantan the poston of
the rm of the canster over the outer lp of the seal (3) as
you rotate the lever ant-clockwse to the vertcal, locked-
on poston Falure to lock the canster n the fully closed
poston, may cause a system leak and/or a reducton n O
absorpton
3 Lft the canster upwards (4) and poston the rm of the
canster over the outer lp of the seal (3)
4 Hold the canster n place, check that there s no lateral
movement
Turn the lever (5) ant-clockwse to the vertcal poston to
lock the canster n place
5 Before clncal use, ALWAYS carry out all the Pre-use
hecks lsted n secton 6 of ths manual
3
4
2
2
3
4
5
3
3
