A200SP Absorber 13 User Manual
4.3 Internal Compressible Volume
Note that the reservor bag s not ftted and the bag mount
blocked when measurements are taken
These fgures are measured wth
1 An absorber ftted wth 1060 mm (42 nch) breathng
hoses complyng wth BS EN ISO 5367, and a Safelock
Y-pece Volume requred to rase the system pressure to 3
kPa (30 cmHO) = 180 ml
2 Absorber only
Volume requred to rase the system pressure to 3 kPa (30
cmHO) = 170 ml
For other dsposable breathng hoses, the suppler of the hose
wll provde compressble volume data
4.4 System Leakage Rate
Seal the patent connecton port and the fully close the
adustable pressure lmtng (APL) valve
These fgures are measured wth
1 An absorber ftted wth 1060 mm (42 nch) breathng hoses
complyng wth BS EN ISO 5367, and a Safelock Y-pece
Absorber ‘ON’, canster n locked-on poston
Leakage rate less than 50 ml/mn at 3 kPa (30 cmHO)
2 Absorber only
Absorber ‘OFF’, canster detached
Leakage rate less than 50 ml/mn at 3 kPa (30 cmHO)
4.5 Canister Capacity and Resistance
4.5.1 Canister Capacity
When flled to the correct level (see secton 53), the canster
nner contaner holds 13 kg (287 lb) of absorbent (1500 ml)
Recommended absorbent
Soda lme, wth a colour ndcator, 4-8 mesh
Use bulk packed (loose) or pre-packs
NOTE
1 The absorber canster s not electrcally conductve
2 leanng and sterlsaton detals are gven n secton 8,
Sterlsaton
4.5.2 Canister Resistance
The resstance of a freshly flled canster s less than 02 kPa
(2cmHO) at 60 L/mn
Specification
