5.5 Heater (option)
WARNIN
Do not touch any electrcal devce connector at the same
tme as the patent
1 heck that the sprometer sensor heater cable (1) s
connected
2 onnect the mans cable (mans electrcal supply) to the
socket (2) on the back of the heater control unt (3)
3 Secure the mans cable wth the safety clp
The heaters operate automatcally
4 heck that the ndcator lamps (4 and 5) are llumnated,
when mans power s connected
5 When shuttng down the system, make sure that the
ndcator lamps are not llumnated and that power to the
system s dsconnected
AUTION
Do not mmerse or autoclave the heater elements (6), heater
control unt (3), or electrcal nterface unt (7) Remove these
components before the absorber assembly s cleaned and
sterlsed (see secton 84)
7
4
1 3
2
7
5 63
Installation and Operation
