Installer Manual 255/LOGIX 742-762-764 - Spare parts
Ref. MKT-IM-021 / A - 20.02.2019 89 / 92
Interconnecting kit & connections
* Not shown
Item Part number Description
Assembly
quantity
1 3019931-2532
Deluxe interconnecting kit 255 twin DN25 mm female 32 mm.
Includes:
- 2x bypass 256 (1040769);
- 1x interconnecting piping elements;
- 2x 32 mm PVC tube adapter kit (1001615)
1
* 1040769 Bypass body assembly (includes bypass installation kit) 1
* 1034302 Bypass repair kit (rotor seals & clips) 1
* 1001615 32 mm PVC tube adapter kit 1
* 3028264 Drain elbow for bypass 256 1
2 Kit-P10 Mounting kit (2 connections) DN 25/32 mm ext x 1" BSP 1
