44 Pentax PocketJet Printer User’s Guide
DIP Switches
The DIP Switch Table lists the feature that each switch
controls and the effect of the ON and OFF settings.
DIP Switch Table
No. Control On Off Page
1 Serial speed See below See below 20
2 Serial speed See below See below 20
3 Self test On Off 14
4 Cleaning On Off 37
5 Paper size and See below See below 26
character set
6 DTR polarity* Active low Active high 20
or
paper size and See below See below 26
character set
7 Xon / Xoff Disable Activate 20
8 Auto-off timer Disable Activate 29
*For Letter/A4 and Letter/Legal model printers.
Serial Speed
◆ 2,400 bps: switches 1 and 2 on
◆ 9,600 bps: switch 1 off and 2 on
◆ 19,200 bps: switch 1 on and 2 off
◆ 38,400 bps: switches 1 and 2 off
NOTE:
If you are using the parallel interface cable,
the settings of switches 1 and 2 don’t matter.
Paper Size and Character Set
Letter/A4 Model:
◆ Letter-size paper and PC-8 character set: switch 5 off
◆ A4-size paper and PC-850 character set: switch 5 on
Letter/Legal Model:
◆ Letter-size paper and PC-8 character set: switch 5 off
◆ Legal-size paper and PC-8 character set: switch 5 on
Letter/Legal/A4 Models:
◆ Letter paper, PC-8 character set: switches 5 and 6 off
◆ Legal paper, PC-8 character set: switches 5 and 6 on
◆ A4 paper, PC-850 character set: switch 5 on and
switch 6 off (or switch 5 off and switch 6 on)
To Next Page
