66 Pentax PocketJet Printer User’s Guide
FUNCTION PARAMETER(s) COMMAND DECIMAL VALUE(s)
Fill Rectangle With Horizontal Line Pattern Esc*c1G 027 042 099 049 071
(continued) Vertical Line Pattern
Esc*c2G 027 042 099 050 071
Diagonal Lines I Esc*c3G 027 042 099 051 071
Diagonal Lines II Esc*c4G 027 042 099 052 071
Square Grid Esc*c5G 027 042 099 053 071
Diagonal Grid Esc*c6G 027 042 099 054 071
Gray, 2% Esc*c2G 027 042 099 050 071
Gray, 10% Esc*c1ØG 027 042 099 049 048 071
Gray, 15% Esc*c15G 027 042 099 049 053 071
Gray, 30% Esc*c3ØG 027 042 099 051 048 071
Gray, 45% Esc*c45G 027 042 099 052 053 071
Gray, 70% Esc*c7ØG 027 042 099 055 048 071
Gray, 90% Esc*c9ØG 027 042 099 057 048 071
Gray, 100% (black) Esc*c1ØØG 027 042 099 049 048 048 071
MACROS
Macro ID Assign Macro ID # Esc&f#Y 027 038 102 [#] 089
Macro Control Start Macro Definition Esc&fØX 027 038 102 048 088
Stop Macro Definition Esc&f1X 027 038 102 049 088
Execute Macro Esc&f2X 027 038 102 050 088
Call Macro Esc&f3X 027 038 102 051 088
Enable Overlay Esc&f4X 027 038 102 052 088
Disable Overlay Esc&f5X 027 038 102 053 088
Delete Macros Esc&f6X 027 038 102 054 088
Delete Temp. Macros Esc&f7X 027 038 102 055 088
Delete Macro ID Esc&f8X 027 038 102 056 088
Make Temporary Esc&f9X 027 038 102 057 088
Make Permanent Esc&f1ØX 027 038 102 049 048 088
MISCELLANEOUS
Show PCL4 Codes Enabled EscY 027 089
Disabled EscZ 027 090
End-of-Line Handling Wrap Long Lines Esc&sØC 027 038 115 048 067
Don’t Wrap Long Lines Esc&s1C 027 038 115 049 067
Ø=Zero (used in commands to distinguish the number zero from the letter 0)
Esc = The “Escape” code. 27 Decimal, or 1B hex.
# and [#] = In many commands, a series of one or more ASCII digits representing the values required by
this command
+++ = Raw data required by this command
Note: When multiple commands are sent in a single stream, all commands except the last one must—if they
end in a letter—end in the lower case version of the letter, not the upper case version shown in this table.
