PePLink Balance Series v4.0 User Manual
Page 9
5.2 PePLink Balance 30 / 300
5.2.1 Front Panel Appearance
5.2.2 LED Indicators
The statuses indicated by the Front Panel LEDs are as follows:
Power and Status Indicators
Power
OFF – Power off
Green – Power on
Status
OFF – System initializing
Red – Booting up or busy
Orange – Power on self test
Green – Ready state
LAN Indicators
Activity
OFF – Port is not connected
Green – Port is connected
Blinking – Port is transferring data
10/100
OFF – 10Mbps
Orange – 100Mbps
WAN Indicators
Activity
OFF – Port is not connected
Green – Port is connected
Blinking – Port is transferring data
10/100
OFF – 10Mbps
Orange – 100Mbps
