PePLink Balance Series v4.0 User Manual
14 Configuration of NAT Mappings
This configuration replaces “DMZ” in firmware versions prior to 3.8. The configuration of
NAT Mappings allows the IP address mapping of all inbound and outbound NAT’ed traffic to
and from an internal client IP address.
The settings to configure NAT Mappings are located at Network > NAT Mappings:
To add a NAT Mapping, click Add NAT Rule, upon which the following screen is displayed:
This is the IP address of the host on the LAN that the system should
map the selected connection IP address correspondences.
This setting specifies the WAN connections and corresponding WAN-
specific Internet IP addresses on which the system should bind on.
Any access to the specified WAN connection(s) and IP address(es) will
be forwarded to the LAN Host.
Note 1: Inbound Mapping is not needed for WAN connections in drop-
in or IP forwarding mode.
Note 2: Each WAN IP address can be associated to one NAT Mapping
only.
