AS-i 3.0 PROFIBUS Gateway in Stainless Steel
PROFIBUS DP
26.9.2013
49
16 bytes digital output (slaves 0 - 31)
20 bytes digital output (slaves 0 - 7B)
24 bytes digital output (slaves 0 - 15B)
28 bytes digital output (slaves 0 - 23B)
32 bytes digital output (slaves 0 - 31B)
Length description
16 bytes digital in/out (slaves 0 - 31)
16 Bytes digital in/out (slaves 0B - 31B)
32 bytes digital in/out (slaves 0 - 31B)
Tab. 10-15.
Length description
Tab. 10-14.
Information!
2 command interfaces can be intergrated.
Length description
2 bytes management (command interface)
4 bytes management (command interface)
8 bytes management (command interface)
11 bytes management (command interface)
12 bytes management (command interface)
34 bytes management (command interface)
36 bytes management (command interface)
Tab. 10-16.
Length description
24 bytes analog input (slaves 29 - 31)
56 bytes analog input (slaves 25 - 31)
88 bytes analog input (slaves 21 - 31)
120 bytes analog input (slaves 17 - 31)
128 bytes analog input (slaves 16 - 31)
16 bytes analog input (slaves 14 - 15)
Tab. 10-17.
