Pepperl+Fuchs IC-KP2-2HB17-2V1D User Manual

2014-02
112
IC-KP2-2HB17-2V1D
Appendix A
Response:
Ele-
ment
Implicit
telegram
Use Ty p e Description
1 Byte 0 Command code 10h Command SR
(single read words)
Byte 1 Number of double words/
Channel/Toggle bit
12h 1 double word = 4 bytes
Channel = element = 1
Toggle bit = 0
Byte 2 Status 00h Command executed.
Byte 3 Reply counter 06h For every ident telegram, the
value on the reply counter
increases by 1.
Byte 4 Data 00h 1. Byte data
Byte 5 Data 01h 2. Byte data
Byte 6 Data 02h 3. Byte data
Byte 7 Data 03h 4. Byte data
2 Byte 8 Command code 10h Command SR
(single read words)
Byte 9 Number of double words/
Channel/Toggle bit
14h 1 double word = 4 bytes
Channel = element = 2
Toggle bit = 0
Byte 10 Status 00h Command executed.
byte 11 Reply counter 06h For every ident telegram, the
value on the reply counter
increases by 1.
byte 12 Data 10h 1. Byte data
Byte 13 Data 11h 2. Byte data
Byte 14 Data 12h 3. Byte data
Byte 15 Data 13h 4. Byte data
3 Byte 16
...
Byte 23
00h Reserved
4 Byte 24
...
Byte 31
00h Reserved
