2014-02
42
IC-KP2-2HB17-2V1D
Commands
7.8.5 Assembly attributes
The attributes of the output object (class 64h) and the input objects (class 65h) appear in
different combinations in the assembly object. 26 assembly instances can be used in pairs for
implicit communication, therefore there are 13 possible combinations. You can select these
combinations either via attribute 100 from instance 0 of the assembly object or by specifying
the combination on the PLC (Forward Open).
The following comparison shows the relationship between input and output instances: Input
instance = output instance + 50d.
A combination of the "heartbeat" and the ident status form the output instance 112 and input
instance 162. Refer to appendix B for a more detailed view of the object model.
7.8.6 Access administration
The assembly object is a collection of attributes from classes 64h and 65h (input and output).
Implicit or explicit access to these objects is possible (via the assembly object). Simultaneous
access is regulated to prevent the attributes from overwriting one another.
Output
instance
Input
instance
Channel size Required/
Ge n e r a t e d
size
Output/Input
byte
1 2 Reser
-
ved
Reser
-
ved
5
(conf.)
Mixed
mode
100d 150d 8* 8 / 8
101d 151d 12* 12 / 12
102d 152d 32* 32 / 32
103d 153d 60* 60 / 60
Sepa-
rated
mode
104d 154d 8 8 8 8 32 / 32
105d 155d 12 12 12 12 48 / 48
106d 156d 32 32 32 32 128 / 128
107d 157d 60 60 60 60 240 / 240
108d 158d 8 8 8 8 8 40 / 40
109d 159d 12 12 12 12 8 56 / 56
110d 160d 32 32 32 32 8 136 / 136
111d 161d 60 60 60 60 8 248 / 248
112d 162d 0 / 10 0 / 10
Table 7.7 * access to mixed mode instance for input/output command object
Implicit data
exchange
Explicit access
Instances from input/output commands
Output
instance
Input
instance
1 2 5
(conf.)
6
Mixed
mode
100d 150d x x x x
101d 151d x x x x
102d 152d x x x x
103d 153d x x x x
