2014-02
94
IC-KP2-2HB17-2V1D
Commands
7.17 Fault/Status messages
Error messages which triggered the identification system
<Triggermode> : 8 bits
0 (00000000b): Trigger mode off
1 (00000001b): Trigger mode on
2 (00000010b): Trigger mode inverted
<WordAddr> : 2 bytes, word start address in the data carrier, range from 0000h to
FFFFh, depending on data carrier type.
<WordNum> : 4 bits, number of words to be read or written, range from 0h to Fh,
depending on data carrier type.
The following applies for IPC03: The word count 0h is used with the
word address 0000h to read the preset data range on the data carrier
("Default Read").
The following applies for IQC33: The word count parameter must be
even-numbered because of the block size of 8 bytes. The word
address then indicates the offset in 8-byte increments.
<Year> : 2 bytes ASCII, hexadecimal encoding, 00h ... 63h
Statu s Meaning
00h The command has been executed without error.
FFh The command is processing.
Statu s Meaning
01h The battery of the read/write tag is weak.
02h Reserved
03h Reserved
04h Incorrect or incomplete command or parameter not in the valid range.
05h No data carrier in the detection range.
06h Hardware error, e.g. error during self-test or R/W head defect.
07h Internal device error.
08h Reserved
09h The parameterized tag type is not compatible with the connected
reading head.
0Ah Several tags in the detection range (UHF).
0Bh Reserved
0Ch Reserved
0Dh Reserved
0Eh Internal buffer overflow.
0Fh Reserved
