4.2.2 Cable connectors for the power supply
Compatible M12 sockets with an open cable end for connecting the IDENTControl Compact to
a power supply are available in different lengths.
Figure 4.3
4.2.3 Connection cable to the Ethernet interface
The IDENTControl Compact has a D-coded, M12 socket and is connected to the network using
a suitable cable.
Figure 4.4
4.2.4 Mounting aid
An aid for mounting the IDENTControl Compact to a DIN mounting rail is available.
4.3 Delivery package
The delivery package contains:
■ 1 IDENTControl Compact unit
■ 1 Quick start guide
■ 2 grounding screws
■ 2 serrated lock washers
■ 2 crimp connectors
Accessories Model number
Length 2 m (straight socket) V1-G-2M-PUR
Length 5 m (straight socket) V1-G-5M-PUR
Length 10 m (straight socket) V1-G-10M-PUR
Accessories Designation
5 m connection cable V1SD-G-5M-PUR-ABG-V45-G
Accessories Model number
Mounting aid ICZ-MH05-SACB-8

Pepperl+Fuchs IC-KP2-2HB17-2V1D Specifications

General

Brand	Pepperl+Fuchs
Model	IC-KP2-2HB17-2V1D
Category	Control Unit
Language	English
