12.1 Object model in the EtherNet/IP protocol
12.2 Identity object (01h)
Class attribute (instance 0)
Instance attributes (instance 1)
Shared services
12.3 Assembly object (04h)
These instances are taken from classes 64h and 65h.
Class Object name Number of instances
01h Identity 1
04h Assembly 25
64h Output command for channel 1 and 2,
IDENTControl Compact and mixed mode
13
65h Input command for channel 1 and 2,
IDENTControl Compact and mixed mode
13
66h Boot-up parameters 4
67h Diagnostics 4
Attribute ID Name Data type Data content Access
authorization
1 Revision UINT 1 Ge t
Attribute ID Name Data type Data content Access
authorization
1 Vendor nu mber UINT 57d Ge t
2 Device type UINT 00h Ge t
3 Product code number UINT 2 Ge t
4 Product major revision
Product minor revision
USINT
USINT
01
25
Ge t
5 Status WORD see below Ge t
6 Serial number UDINT Unique 32-bit
value
Ge t
7 Product number String from
USINT
IC-KP2-2HB17-
2V1D
#200877
Ge t
Service code integrated in service designation
Class level Instance level
0Eh Ye s Yes Get attribute single
05h No Yes Reset
