IC-KP2-2HB17-2V1D
Appendix B
Shared services
12.7 Diagnostics object (instances 67h - 5)
Class attributes (instance 0)
Instance attributes (instances 1 and 2, channels 1 and 2)
Instance attributes (instance 5, IdentControl)
Shared services
Service code integrated in service designation
Class level Instance level
0Eh Yes Yes Get attribute single
10h Yes Yes Get attribute single
Attribute ID Name Data type Data content Access
authorization
1 Revision UINT 1 Ge t
100 Refresh all BOOL 0 Get / Set
101 Multiplex mode BOOL 0 Ge t
102 Trigger condition 3 USINT 0 Ge t
103 Trigger condition 4 USINT 0 Ge t
104 Version gateway Bytes [52] 0 Ge t
Attribute ID Name Data type Data content Access
authorization
1 Ta g t yp e USINT 0 Ge t
2 Version Bytes [52] 0 Ge t
Attribute ID Name Data type Data content Access
authorization
1 Unused
2 Version Bytes [52] 0 Ge t
Service code integrated in service designation
Class level Instance level
0Eh Yes Yes Get attribute single
10h Yes No Set attribute single
