IC-KP2-2HB17-2V1D
Product Description
2014-02
15
4.7 Displays and Controls
LEDs
Operating controls
Description Function Statu s des cription
1
2
Status display for
the read/write
heads
LED illuminates green when there is an active command on
the read/write head.
LED illuminates yellow for approx. 1 second when a
command is executed successfully.
CH1
CH2
Displays the
read/write heads
connected
(channel)
LED illuminates green when a read/write head is connected
to channel 1 or channel 2.
LED illuminates red if a configuration error occurs.
PWR/ERR Status display for
the IDENTControl
Compact
LED illuminates green when the IDENTControl Compact is
connected to a power supply and the interface is ready for
operation.
LED illuminates red if there is a hardware error or a
PROFINET name has been assigned and no PROFINET
connection has been established.
LED illuminates yellow while the IDENTControl Compact
starts up. The start-up process lasts approximately 20
seconds
LED flashes green if a signal is sent to the IDENTControl
Compact via the "Flashing" PROFINET function or if there is
an internal data overflow.
Link/Traffic Connection/networ
k activity for the
relevant channel
(1/2)
LED is off until initial communication is made via Ethernet.
LED illuminates green when a connection to the network is
established.
LED flashes yellow at the same speed as the data being
sent.
ADDR
STATE
Status display for
address setting
LED flashes green when the IDENTControl Compact is
ready for the address to be entered using the rotary switch.
LED illuminates green when one digit of the address is
entered successfully using the rotary switch.
Description Function Configuration option
Rotary switch Device address setting 0 ... F
CH2CH2CH1CH1
12
PWR/ERR
0
8
C
4
F
7
B
3
E
6
A
2
D
5
9
1
Link/
Traffic
Link/
Traffic
Address
configuration
Address
state
