Pepperl+Fuchs IC-KP2-2HB17-2V1D User Manual

2014-02
56
IC-KP2-2HB17-2V1D
Commands
7.10 Command overview
The commands in the list are described in detail on the following pages.
System commands
Standard read/write commands
Fixcode
Read data
Write data
Special command modes
Password mode with IPC03
IPC03 configuration
Command code Command description
Abbre-
viation
4d 04h See "Change tag (CT)" on page 58 CT
2d 02h See "Quit (QU)" on page 60 QU
23d 17h See "Configuration store (CS)" on page 61 CS
22d 16h See "Reset (RS)" on page 62 RS
155d 9Bh See "Set multiplexed mode (MM)" on page 62 MM
156d 9Ch See "Set trigger mode (TM)" on page 63 TM
Command code Command description
Abbre-
viation
1d 01h See "Single read fixcode (SF)" on page 64 SF
29d 1Dh See "Enhanced buffered fixcode (EF)" on page 65 EF
Command code Command description
Abbre-
viation
16d 10h See "Single read words (SR)" on page 66 SR
25d 19h See "Enhanced buffered read words (ER)" on page 67 ER
Command code Command description
Abbre-
viation
64d 40h See "Single write words (SW)" on page 68 SW
26d 1Ah See "Enhanced buffered write words (EW)" on page 69 EW
Command code Command description
Abbre-
viation
24d 18h See "Set password mode (PM)" on page 72 PM
65d 41h See "Change password (PC)" on page 73 PC
66d 42h See "Set password (PS)" on page 74 PS
Command code Command description
Abbre-
viation
97d 61h See "Single get configuration (SG)" on page 76 SG
104d 68h See "Enhanced buffered get configuration (EG):" on page 77 EG
