Pepperl+Fuchs IC-KP2-2HB17-2V1D User Manual

2014-02
74
IC-KP2-2HB17-2V1D
Commands
Set password (PS)
Command:
Response:
The command PSsets the password, which the R/W head communicates to the data carrier in
password mode.
Byte Ty p e Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (42h) 0 1 0 0 0 0 1 0
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte 4 Reserved 0 0 0 0 0 0 0 0
Byte 5 Reserved 0 0 0 0 0 0 0 0
Byte 6 Password 00h ... FFh <PSW> (byte 3)
Byte 7 Password 00h ... FFh <PSW> (byte 2)
Byte 8 Password 00h ... FFh <PSW> (byte 1)
Byte 9 Password 00h ... FFh <PSW> (byte 0)
Byte Ty p e Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 0 1 0 1
Byte 2 Command code (42h) 0 1 0 0 0 0 1 0
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte 4 Statu s <Status>
Table 7.21 * this byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
