2014-02
20
IC-KP2-2HB17-2V1D
Commissioning
The parameters are volatile and non-volatile parameters. Volatile parameters are reset to their
default setting when the system is switched off and on again.
Non-volatile parameters
Volatile parameters
Configure the R/W system using the system commands described (see chapter 7.11). "99" is
preset as the tag type.
6.4 Setting the IP address
The IP address of the IDENTControl Compact is preset to 169.254.10.12. The way in which the
IP address is modified depends on if you are using a DHCP server.
If you are not using a DHCP server, the IP address is manually assigned: Either select the IP
address using the rotary switch or start the device with the preset IP address and specify the
new IP address on the device website.
If you are using a DHCP server, the server assigns the IP address to the IDENTControl
Compact.
Parameter Default setting Value range
Ge n e r a l
Multiplex mode Off On / off
Read/write head
Trigger mode Off On / off
Tag t y p e 99 00 ... 99
Ethernet interface
MAC address 00:0D:81:xx:xx:xx 00:0D:81:xx:xx:xx
DHCP Off On / off
IP address 169.254.10.12 yyy.yyy.yyy.yyy
Standa rd gateway 169.254.254.1 yyy.yyy.yyy.yyy
Subnet mask 255.255.0.0 yyy.yyy.yyy.yyy
Assembly inst. Out 100d 100d ... 112d
Data hold time 50d x 10 ms 0d ... 255d x 10 ms
Parameter Default setting Value range
R/W head
Password mode Off on / off
Password 00000000 00000000 ... FFFFFFFF
Note!
We recommend using a fixed preset IP address in order to avoid system malfunctions.
Note!
The rotary switch used to select the device address is located on the underside of the
IDENTControl Compact. This rotary switch is no longer accessible once the IDENTControl
Compact is installed.
