IC-KP2-2HB17-2V1D
Commands
2014-02
77
Enhanced buffered get configuration (EG):
Command:
Response:
The R/W head attempts to read a word in the configuration range from the address
<ConfAddr> until successful. Only data that changes is transferred via the interface, i.e. the
R/W head transfers data whenever it reads a new data carrier or whenever it reads a data
carrier where there was previously no R/W head within the detection range.
The status '05h' (read/write command) is output when the data carrier leaves the detection
range or if the data carrier is not yet within the detection range when the command is executed.
If two data carriers enter the read range one immediately after the other, the status '05h' is not
issued between the two readings.
Byte Ty pe Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 0 1 0 1
Byte 2 Command code (68h) 0 1 1 0 1 0 0 0
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte 4 Reserved 0 0 0 0 0 0 0 0
Byte 5 Address in the configuration range <ConfAddr>
Byte Ty pe Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (68h) 0 1 1 0 1 0 0 0
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
Byte 6 Data 00h ... FFh <Data>
Byte 7 Data 00h ... FFh <Data>
Byte 8 Data 00h ... FFh <Data>
Byte 9 Data 00h ... FFh <Data>
Table 7.23 * this byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
