Pepperl+Fuchs IC-KP2-2HB17-2V1D User Manual

2014-02
60
IC-KP2-2HB17-2V1D
Commands
Quit (QU)
Command:
Response:
The command running on this channel is interrupted.
4)
IUC7* type read/write tags can only be used with read/write head IUH-F117-V1 in combination with certain
control interfaces.
5)
The tag type configured in the read/write head as the default is selected.
6)
Read/write tags can have 4-byte (older versions) or 7-byte UIDs. IQC42 and IQ C43 type read/write tags
from Pepperl+Fuchs generally have 7-byte UIDs.
Note!
In a plant where only one tag type is used, it is advantageous to permanently configure that tag
type so that the read/write head detects the tag quicker.
Byte Type Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 0 1 0 0
Byte 2 Command code (02h) 0 0 0 0 0 0 1 0
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte Type Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 0 1 1 0
Byte 2 Command code (02h) 0 0 0 0 0 0 1 0
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
Table 7.9 * this byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
