IC-KP2-2HB17-2V1D
Commands
2014-02
59
'2' '4' IQC24 my-D SRF55V10P
(Infinion)
Read/write read
only code
928 8 13.56 MHz
'3' '1' IQC31 Tag-it HF-I Standard (Texas
Instruments)
Read/write read
only code
32 8 13.56 MHz
'3' '3'
IQC33
2)
FRAM MB89R118 (Fujitsu) Read/write read
only code
2k 8 13.56 MHz
'3' '4' IQC34 FRAM MB89R119 (Fujitsu) Read/write read
only code
29 8 13.56 MHz
'3' '5' IQC35 I-Code SLI-S (NXP) Read/write read
only code
160 8 13.56 MHz
'4' '0' IQC40 All ISO 14443A compliant
read/write tags
Read only code -
4/7
6)
13.56 MHz
'4' '1' IQC41 Mifare UltraLight MF0 IC
U1 (NXP)
Read/write read
only code
48 7 13.56 MHz
'4' '2'
IQC42
3)
Mifare Classic MF1 IC S50
(NXP)
Read/write read
only code
752
4/7
6)
13.56 MHz
'4' '3'
IQC43
3)
Mifare Classic MF1 IC S70
(NXP)
Read/write read
only code
3440
4/7
6)
13.56 MHz
'5' '0' IDC-...-1K P+F Read/write read
only code
125 4 250 kHz
'5' '2' ICC-... P+F Read only code 28 7 250 kHz
'7' '2'
IUC72
4)
UCode-EPC-G2XM (NXP) Read/write read
only code
64 8 868 MHz
'7' '3'
IUC73
4)
Higgs-2 (Alien) Read only code - 96 868 MHz
'7' '4'
IUC74
4)
UCode-EPC-G2 (NXP) Read/write read
only code
28 96 868 MHz
'7' '5'
IUC75
4)
Monza 2.0 (Impinj) Read only code - 96 868 MHz
'7' '6'
IUC76
4)
Higgs-3 (Alien) Read/write read
only code
56 240 868 MHz
'8' '0' - All Class 1 Gen 2 compliant
read/write tags
- - Max. 96 868 MHz
'9' '9' Depends
on the
reader
5)
- - - - -
Ta g t y p e P+F desig-
nation
Chip type Access Writable
memory
[bytes]
Read only
code
length
[byte]
Frequency
range
High
byte
Low
byte
1)
IQC20 is not an actual tag type as such, but is used to read the UID (read only code) of all ISO 15693
compliant read/write tags.
2)
Read/write tag IQC33 can only be used in combination with a IQH1-... read/write head. The memory is
divided into 8-byte blocks (instead of 4-byte blocks). You must enter a continuous initial address for write
commands SR, ER, SW and EW.
<WordNum> specifies the number of 8-byte blocks (here, max. 7) and must be an even number.
3)
Read/write tags IQC40–IQC43 can only be used in combination with a IQH2-... read/write head.
<WordNum> specifies the number of 16-byte blocks and must be a multiple of 4.
The memory can be encrypted for each sector (1 sector = 4 blocks of 16 bytes).
The default key in the tag and reader is FF FF FF FF FF FF
ASCII
. The key in the reader can be read
using the Read param command and written using the Write param command (see System
Commands). The key is only changed in the reader during this process and not in the tag!
The key in the reader is stored in the non-volatile memory.
